FY2402000
Fuyuang
| Quantity: | |
|---|---|
| Input | 100-240VAC, 50/60Hz |
| Output voltage | 24V |
| Output current | 2A |
| Dimension | 105*43.5*30mm |
| Inrush current | 15A for a cold start |
| No load standby power | ≤ 0.21W |
| Efficiency | 88% the Min. |
| Operating temperature | -29ºC ~+45.5ºC |
| Storage temperature | -40ºC ~+75ºC |
| Over load protection | Auto recovery |
| Short circuit protection | Auto recovery |
| MTBF | 30000 hours full rated load operation at 25ºC |
| Inspection | MIL-STD-105D II AQL: CRI 0; MAJ 0.25; NIN 2.5 |
| Delivery time | 2-3 weeks |
| Payment | 30% deposit, the rest 100% T/T before shipping |
*Global certificates: CE,GS,CB,UL,CUL,FCC,PSE,SAA,C-TICK,RCM,KC,CCC,ROSH,REACH,ERP,MEPS,NRcan.
*All power supply,battery chargers and power adapters are 100% burn-in tested and inspected with automatic test equipmrnt(ATE).
*100% inspection: no load voltage, load voltage,short circuit, OCP,OVP, Ripple Voltage, Primary, HIPOT test and general appearance.
*Safety standard: UL60950,EN55022,EN55015,EN61547,EN61000,EN60335,EN61558,EN61347-1,EN61347-2 -13,EN62233,EN60529,GB4943.1,GB9254,GB17625,J60950,J55022,J3000,J61347-1,J61347-2-13,J55015,J55014,J61558,K00022,K00024.
*We back our items with three-year guarantees.
*Free maintance and testing services within 2years of purchase
*Key components made by ourselves, such as Transformer, case, and DC cord.
*Lead by general engineer of 25 years experience.
*Both OEM and ODM are vailable
